Online Configuration Guide of the HVS-100/110

Model Selection

Please select preference (choose one, and click "NEXT")

Separate Main Unit/Control Panel Type. The main unit offers exceptional expandability to facilitate the addition of various input/output cards.

Integrated Main Unit/Control Panel Type. The compact design proves simple portability. The inclusion of ample video input and output functionality, making it ideal for use in small OB vans and broadcasting helicopters.

Control Panel Selection

Please select your operation style (choose one)

The control panel has been laid out with a design for professionals. It is equipped with dedicated bus buttons, AUX buttons, a fader controller and direct user buttons for various functions, based on knowledge from field operators.

Input/Output Selection

Please select optional cards for each slot. (choose one each)

Slot A

4 channels of HD/SD-SDI input card. Frame Synchronizer function for all inputs and re-size (amplify) function for 2 inputs are provided.

2 channels of analog video signal input card. Selectable between analog composite and analog component (HD or SD) for each terminal.

HDMI and VGA have been mounted on a single card. 2 input channels are possible to use both. (HDCP-incompatible.)

Thunderbolt™ 2 I/O expansion card (4K format is not supported)

Slot B

4 channels of HD/SD-SDI input card. Frame Synchronizer function for all inputs and re-size (amplify) function for 2 inputs are provided.

2 channels of analog video signal input card. Selectable between analog composite and analog component (HD or SD) for each terminal.

HDMI and VGA have been mounted on a single card. 2 input channels are possible to use both. (HDCP-incompatible.)

2 channels of analog video signal output card. Selectable between analog composite and analog component (HD or SD) for each terminal.

2 channels of HD/SD-SDI output card. A down-conversion is available on these two outputs.

HDMI and VGA have been mounted on a single card. 2 output channels are possible to use both. (HDCP-incompatible.)

Thunderbolt™ 2 I/O expansion card (4K format is not supported)

Slot C

2 channels of analog video signal output card. Selectable between analog composite and analog component (HD or SD) for each terminal.

2 channels of HD/SD-SDI output card. A down-conversion is available on these two outputs.

HDMI and VGA have been mounted on a single card. 2 output channels are possible to use both. (HDCP-incompatible.)

Thunderbolt™ 2 I/O expansion card (4K format is not supported)

Other Options

Please choose from the following options:

AUX Remote Control Panel

Ethernet type or ARCNET type are available for AUX remote. Please choose from the following options:

AUX Remote Unit: Ethernet Type

Up to 5 units are selectable.

sets

sets

sets

sets

AUX output can be remotely controlled. There are models of 16, 32, and 64 buttons.

AUX Remote Unit: ARCNET Type

Up to 5 units can be daisy-chained via ARCNET.

sets

sets

sets

sets

Selectable AUX Remote Control Panels from 8 and 16 buttons. The 8-button panel is half rack width and 16-button panel with full rack width. A panel extension kit enables the button interface to extend. (require HVS-100ARC, ARCNET card)

Remote Control Panel

Remote control panel can be connected via RS-422.

1U control panel can be used in a rack. It comes with bus buttons, a compact LCD display showing the wipe patterns, and buttons like Rotary Encoder, optimized for button operation. Can be used as a Main Panel as well as AUX Remote Panels like HVS-AUX8/16.

Tally Interface Unit

Up to 3 units can be connected

Open Collector-type unit

sets

sets

Relay-type unit

sets

sets

Open collector-type, HVS-TALOC20/32, or relay-type, HVS-TALR20/32 allow to connect to Tally system. The line-up consists of 20 and 30 contact-closure types.

ARCNET Card

The card enables the Arcnet connection in case your system requires AUX panel, etc.

3 Gbps Expansion Software

Capable of 3G-SDI/4K signal
Software to support 3G-SDI and 4K (3840 x 2160, Square Division) signals

Editor Interface Software

Interface software to connect with an external device, supporting BVS, DVS and GVG protocols.

Virtual Link Software

The software which supports Virtual Studio System "digiStorm" and VRCAM.

If the configuration you selected is fine to proceed, please go to Customer Information.
